General Flame Retardant Conveyor Belt

EVER JOY / INDUSTRIAL CONVEYOR BELTING

General Flame Retardant Conveyor Belt

Русский

Rubber-covered EP/NN multi-ply construction | Above-ground industrial service

Surface coal handling and power plants — Coal, coal fines, coke and mixed bulk solids
Ports and stockyards — Coal, ores and other bulk solids
Steel and mineral processing — Raw materials, concentrates, coke feed
General flame-retardant conveyor belt rolls in yellow packaging

1. Product overview and construction benefits

For above-ground bulk conveying systems with defined flame-retardance and electrical conductivity requirements. Specify the rubber covers and textile carcass against the conveyed material, equipment layout and safety category, while retaining appropriate tensile strength, abrasion performance, troughability and splice compatibility.

EVER JOY general flame-retardant belting combines EP (polyester/nylon) or NN (nylon) textile reinforcement, rubber covers and bonding rubber. Typical applications include surface coal handling, power plants, ports, steelworks and industrial bulk transport. Flame retardance is evaluated under defined ignition tests; it does not mean that the belt is non-combustible or a substitute for conveyor fire prevention design.

  • Rubber-covered multi-ply EP/NN construction matched to rated strength and pulley duty.
  • Safety requirements can be specified with K1, K2 or K3 test criteria under GB/T 10822-2014.
  • Flammability and electrical conductivity are evaluated as separate properties.
  • Width, top/bottom covers, carcass and roll lengths can be specified for the conveyor.
  • Inspection and acceptance documents can be agreed with the procurement specification.

2. Applications and limitations

Industry / locationTypical materialsSelection focus
Surface coal handling and power plantsCoal, coal fines, coke and mixed bulk solidsIdentify dust and electrical/static risk
Ports and stockyardsCoal, ores and other bulk solidsCheck weather, speed and pulley layout
Steel and mineral processingRaw materials, concentrates, coke feedCheck separate heat and abrasion demands
Chemical plants and factoriesGranules, powders and packaged goodsSpecify fire and anti-static requirements

GB/T 10822-2014 applies to general-purpose, rubber-covered textile conveyor belts for above-ground industrial service. Compliance with this standard does not constitute approval for underground coal-mine use. PVC/PVG solid woven belts are a different construction requiring separate assessment under applicable mining rules and product approvals.

3. Multi-ply construction and material functions

The top rubber cover contacts the load and is selected for its required fire behaviour and mechanical duty. The EP/NN fabric carcass carries the longitudinal tension; black bonding rubber binds the plies and covers; the bottom cover protects the reinforcement and contacts rollers and pulleys. The illustrated section explains the physical layers, not a tested fire rating.

A fabric-reinforced rubber belt cross-section for structural illustration, not a flame-rating certificate.

General Flame Retardant Conveyor Belt — construction illustration

4. K1 / K2 / K3 laboratory flame safety criteria

The following compares key criteria used in GB/T 10822-2014. Each grade has a different sample configuration; the afterflame values must not be compared without the test conditions. These are standard acceptance criteria, not batch test results for EVER JOY.

GradeSpecimens and afterflame limitsProcurement interpretation
K13 cover-intact + 3 cover-removed specimens; combined afterflame ≤45 s; each covered specimen ≤15 s and each cover-removed specimen ≤20 sTests belt specimens with covers intact and with covers removed, not separate raw cover or carcass materials
K26 cover-intact specimens; combined afterflame ≤45 s; no individual result >15 sCommon above-ground flame-retardant requirement
K33 cover-intact specimens; mean afterflame ≤60 sDifferent sample set; not directly comparable to K1/K2 totals
Electrical resistance: where specified under the applicable general-purpose belt rules, the limit is ≤3×10⁸ Ω. Relevant rules also address reignition. Small-scale flame resistance does not replace conveyor-system fire risk assessment.
General Flame Retardant Conveyor Belt — construction illustration

5. Rubber cover mechanical grades and belt properties

The H/D/L cover grades below provide a mechanical-property comparison used in GB/T 10822-2014-based specifications. Cover grade and flame safety grade are separate choices and must both appear in the technical specification.

Cover gradeTensile strength (MPa) ≥Elongation at break (%) ≥Abrasion loss (mm³) ≤
H24450120
D18400100
L15350200

Values are standard comparison criteria for the designated grades, not verified results for all EVER JOY products. Actual order acceptance is based on the specified grade and corresponding reports.

6. Carcass, dimensions and order specification

Specify finished-belt nominal strength in N/mm. For example, EP400/4 means a 400 N/mm finished belt with four fabric plies; this must not be confused with the strength designation of each individual fabric ply.

ParameterQuotation example / inputWhat to specify
Carcass and strengthEP/NN; e.g., EP400/4 or EP630/4Finished-belt rating in N/mm and number of plies
Width and lengthe.g., 650 / 800 / 1000 / 1200 mm widthFactory maximum production width approx. 2200 mm
Rubber coverse.g., 4+2, 5+2 or 6+3 mmTop/bottom thickness and H/D/L grade
Fire and anti-static safetyK1, K2 or K3; resistance limitState exact standard and sampling method
Conveyor dutySpeed, incline, pulley diameters, trough angleBulk material, lump size and impact
DeliveryQuantity, roll lengths, core and destinationOpen-ended/endless, splice and roll-weight constraints

Dimensions and model codes are quotation examples, not a stock or certification listing. Confirm the production and testing scope for the exact construction.

7. How to specify flame-retardant belting

01 Identify the location: above ground, open stockyard, enclosed plant or underground; supply the site safety rules.

02 Specify the safety grade: K classification or the relevant EN 12882 category, including the required test methods.

03 Select carcass and covers: nominal strength, EP/NN plies, rubber thickness, cover mechanical grade and width.

04 Define documentation: flame aftertime, electrical resistance, adhesion, tensile strength and batch inspection scope.

05 Check system and shipment: pulley diameters, splice method, belt speed, roll dimensions and destination.

8. Chinese, ISO and European standards

Standard / editionRole and applicability
GB/T 10822-2014Product standard for general-purpose rubber-covered textile belts; not an underground mining approval
GB/T 39795-2021Chinese general-purpose conveyor belt safety requirements for electrical and flammability behaviour
GB/T 3684-2021Chinese belt electrical conductivity specification and test method
ISO 340:2022Small-scale laboratory flammability requirements and test method
ISO 284:2025Electrical conductivity specification and test method, assessed separately from flame testing
EN 12882:2015 / DIN EN 12882:2015-11European above-ground general-purpose belt electrical and flammability safety categories
ISO 14890:2026General textile carcass and cover construction reference; not proof of flame resistance
ISO 252:2023 / ISO 283:2023Adhesion and full-thickness tensile test methods for textile conveyor belts

Russian, Central Asian and other markets may require additional GOST provisions, approvals or tender-specific tests. Citing a standard in a quotation is not a certification for an untested model.

9. Inspection and technical documentation

InspectionTechnical record
Fire behaviourSample preparation, ignition, afterflame, reignition and required grade
Electrical conductivityResistance result, test method, environmental conditioning and identification
Mechanical characteristicsRubber tensile, elongation, abrasion, belt tensile strength and adhesion
Dimensions and appearanceWidth, length, thickness, cover dimensions, tracking and visual condition
Delivery recordsModel and batch marking, packaging, roll weight and agreed reports

For tenders or higher-risk sites, specify the exact third-party inspection, sample quantity, approval records and factory batch tests in the contract.

10. Frequently asked questions

01 Can K1, K2 and K3 be substituted?

Not on the grade name alone. The number and type of test specimens and afterflame criteria differ. Supply the project-required class.

02 Does “flame retardant” mean fireproof?

No. It describes behaviour under defined tests and cannot replace fire detection, protection or safe installation design.

03 Is anti-static behaviour automatic with a flame-retardant cover?

No. Electrical resistance and flame behaviour must be specified and measured independently.

04 Does ISO 340 prove approval for underground coal mines?

No. Underground use requires the applicable local requirements and approval for the exact belt construction.

05 What is the difference from PVC/PVG solid woven belts?

This is a rubber-covered EP/NN multi-ply construction; PVC/PVG uses a different woven core and cover system, with distinct approval and splice considerations.

06 Can the belt also be heat- or oil-resistant?

Multiple functions require formulation and verification against all relevant tests. Describe the actual temperature and chemicals.

07 What information is needed for quotation?

Width, length, finished strength, carcass plies, cover thickness, H/D/L grade, K grade, anti-static limits, quantity and destination.

08 Can inspection documents be supplied?

The scope of batch testing and inspection documents should be specified in the order. Evidence must correspond to the product and production batch.

11. Manufacturing and export support

EVER JOY serves industrial buyers internationally. Our manufacturing factory is in Guzhen County, Bengbu, Anhui, China. The site covers around 140 mu (93,333 m²) with a combined production capacity of approximately 20,000 m of conveyor belt per day. We support specification review, packing, shipping coordination and factory visits by appointment.

Send the required flame class, anti-static criteria and full belt specification for a technical review and quotation.
